Stainless Steel Customized Slot And Shape Wire Mesh Water Filter For Well Drilling
Materials:
The Wire Mesh Water Filter is not only support but also filtration for the well drilling.The wire mesh water filter is special filtration.The surface material is wedge wire.It has high strength and rigidity to support the drilling hole.The wedge wire is twined on the rods and welded them together. So the filter is good at high pressure and keep firm and non-defrnation.The material is stainless steel.It's safe for food and antirust.So it is can be used for drinking water.
Nominal Diameter (in) | ID (mm) | OD (mm) | Wt (Kg/m) | Collapse Strength (bar) | Nominal Diameter (in) | ID (mm) | OD (mm) | Wt (Kg/m) | Collapse Strength (bar) |
| 2-3/8” | 45 | 60.3 | 4 | 90 | |||||
| 2-7/8” | 58 | 73.0 | 4 | 90 | |||||
| 4-1/2” | 100 | 114.3 | 5 | 14 | 4-1/2” | 100 | 114.3 | 8 | 60 |
| 5-1/2” | 124 | 139.7 | 7 | 8 | 5-1/2” | 124 | 139.7 | 10 | 50 |
| 6-5/8” | 150 | 168.3 | 9 | 20 | 6-5/8” | 150 | 168.3 | 12 | 50 |
| 8-5/8” | 197 | 219.1 | 15 | 15 | 8-5/8” | 197 | 219.1 | 20 | 60 |
| 9-5/8” | 222 | 244.5 | 17 | 9 | 9-5/8” | 222 | 244.5 | 25 | 60 |
| 10-3/4” | 247 | 273.1 | 20 | 10 | 10-3/4” | 247 | 273.1 | 30 | 45 |
| 12-3/4” | 298 | 323.9 | 24 | 10 | 12-3/4” | 298 | 323.9 | 37 | 40 |
| 13-3/8” | 316 | 339.7 | 30 | 9 | |||||
| 16 | 378 | 406.4 | 34 | 9 | |||||
| 20 | 476 | 508.0 | 53 | 9 | |||||
| Applied for shallow well or general screen | Greater strength, larger filter area Applied for medium depth wells or deep wells | ||||||||
The characteristic of wedge wire screen:
1. A continuous slot opening up which significantly boosts the accessible wide open region, hence offering greater access to the drinking water displaying zone
2. A V-shaped wire which helps prevent blocking and guarantees an uninterrupted flow.
3. A uniform and efficient well development due to the continuous slot opening up.
4. Step ladder-like wire welded displays use a powerful framework and available location, in addition to accurate port measurement.
5. Ladder-like cable welded monitors hold the highlights of effortless backwashing, last long, safety and stability in addition to low complete price.
Maximazing movement rates :
When considering display screens of the same duration, diameter and port size, flow rates through V-designed well displays can beThree instances greater than connection-port screensNine periods beyond slotted housing
No blocking port :
Continuous-slot well display screens have V-shaped availabilities that narrowest in the outside deal with and enlarge inwardly, as a result, oversized contaminants are retained beyond the monitor and contaminants transferring from the filter outdoors starting can enter the display.
Decrease in functioning cost :
Using a Continous-port well display screen, price savings is possible in pumping fees. Decrease through-port velocities mean that strain declines are minimized, consequently :
Drawdowns are lowered, Much less power is essential for moving, Stream prices are elevated, Significantly less beach sand in water lowers put on on the pumping systems.
Application:
1.Mining.
2.Coal
3.Oil
4.Chemical
5Environmental protection
6.Liquid and air filtration
7.drinking water safely
Packages:
The delivery:
Please Meet us on The http://www.wedgefilter.com,we will give you sincere sevice and an unbeatable price.
|
|
