180 200 250 100 % Pure Copper Woven Wire Mesh Ultra Thin

180 200 250 100 % Pure Ultra Thin Copper Woven Wire Mesh

Copper Woven Wire Mesh Introduction:

Copper mesh series products are available in copper wire mesh, bronze wire mesh, and brass wire mesh. They look similar in appearance and color. Due to the different compositions of metal materials, each product has different characteristics and use effects. Copper mesh products are widely used in building decoration, household, electrical, technology, and other industries.

Copper mesh and copper wire cloth specification
Mesh/inch	Wire diameter			Opening (mm)
Mesh/inch	SWG	mm	Inch	Opening (mm)
2	15	1.80	0.071	10.90
2	16	1.60	0.063	11.10
3	16	1.60	0.063	6.866
4	16	1.60	0.063	4.75
4	18	1.20	0.047	5.15
4	20	0.91	0.036	5.44
4	22	0.711	0.028	5.64
5	20	0.91	0.036	4.17
6	21	0.80	0.031	3.433
6	22	0.711	0.028	3.522
8	22	0.711	0.028	2.46
8	23	0.610	0.025	2.565
8	24	0.511	0.022	2.616
8	26	0.457	0.018	2.7
10	23	0.610	0.025	1.91
10	24	0.511	0.022	1.98
10	25	0.508	0.020	2.032
10	27	0.417	0.016	2.1
12	24	0.511	0.022	1.52
12	26	0.457	0.018	1.66
14	25	0.508	0.020	1.30
14	26	0.457	0.018	1.357
14	27	0.417	0.016	1.397
16	29	0.345	0.013	1.243
16	30	0.315	0.012	1.27
18	26	0.457	0.018	0.98
18	30	0.315	0.012	1.096
18	31	0.295	0.010	1.16
20	27	0.417	0.016	0.86
20	30	0.315	0.012	0.955
20	31	0.295	0.010	1.02
20	32	0.274	0.009	0.88
22	30	0.315	0.012	0.840
22	32	0.274	0.009	0.88
24	28	0.35	0.014	0.71
24	30	0.315	0.012	0.743
24	33	0.254	0.008	0.8
26	31	0.295	0.010	0.682
28	31	0.295	0.010	0.612
30	29	0.345	0.013	0.52
30	32	0.274	0.009	0.573
30	33	0.254	0.008	0.64
30	34	0.234	0.007	0.613
32	33	0.254	0.008	0.540
34	34	0.234	0.007	0.513
36	34	0.234	0.007	0.472
38	35	0.213	0.005	0.455
40	31	0.295	0.010	0.38
40	36	0.193	0.008	0.442
40	38	0.152	0.0060	0.485
42	36	0.193	0.0076	0.412
44	37	0.173	0.0068	0.404
46	37	0.173	0.0068	0.379
48	37	0.173	0.0068	0.356
50	32	0.229	0.009	0.28
50	34	0.234	0.007	0.32
50	37	0.173	0.0068	0.335
50	39	0.132	0.0052	0.378
60 × 50	36	0.193	0.0076	-
60 × 50	37	0.173	0.0068	-
60	33	0.191	0.0075	0.23
60	37	0.173	0.0068	0.250
60	40	0.122	0.0048	0.301
60	42	0.10	0.0040	0.32
70	39	0.132	0.0052	0.231
70	41	0.112	0.0044	0.251
80	35	0.213	0.005	0.18
80	36	0.193	0.008	0.22
80	40	0.122	0.0048	0.196
80	42	0.102	0.004	0.216
90	41	0.112	0.0044	0.170
90	43	0.091	0.0036	0.191
100	36	0.193	0.008	0.15
100	42	0.102	0.004	0.152
100	43	0.091	0.0036	0.164
100	46	0.061	0.0024	0.198
120 × 108	43	0.091	0.0036	-
120	44	0.081	0.0032	0.131
120	45	0.071	0.0028	0.14
140	45	0.071	0.0028	0.11
140	46	0.061	0.0024	0.120
145	46	0.061	0.0024	0.1168
150	46	0.061	0.0024	0.108
160	46	0.061	0.0024	0.098
180	46	0.061	0.0024	0.081
180	47	0.051	0.002	0.090
200	47	0.051	0.002	0.076

180 200 250 100 % Pure Copper Woven Wire Mesh Ultra Thin

Copper Woven Wire Mesh Features:

· Aesthetic and attractive appeal.

· High strength and unique texture.

· Bright transparency and refined structure.

· Fashionable design and practical function.

· UV resistance and fire resistance.

· Shock resistance and impact resistance.

· Excellent sound insulation and safety performance.

· More optional choice and long service life.

copper Woven Wire Mesh Appcation :

(1)Energy storage
(2)Electric heaters
(3)Pest control fumigation
(4)Tactical military shelters & modular containers
(5)Robotics & power automation
(6)Gamma irradiate

(7)Health, body and mind enrichment
(8)Space program initiatives (NASA)

180 200 250 100 % Pure Copper Woven Wire Mesh Ultra Thin

Packing:

Bobbin package, PP bags and wooden pallets, wooden case.
